Whirlpool W11501934 Harness (Wire) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11501934 replaces AP6995536, W11103760.

Description

This OEM wiring harness connects the appliance's electrical components to restore reliable power and signal paths. Replaces a damaged or burnt harness to help stop intermittent operation and wiring-related error codes. What it does:

• Carries power and control signals between components to enable normal operation.
• Replaces frayed, melted, or broken wiring that can cause intermittent power or failures.
• Helps resolve symptoms such as no power to modules, lights, or motors and erratic component behavior.
• Restores factory routing and connector fit for reliable connections.

What's included: One wiring harness as pictured and specified by the manufacturer. Install notes:

• Always disconnect the appliance from power (unplug or shut off breaker) before servicing.
• Follow the OEM wiring diagram and secure harness routing to avoid pinching or contact with moving parts.
• Match connectors and colors; do not splice unless using proper connectors and techniques.
