Whirlpool R9800119 Harness, Wiring (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number R9800119 replaces AP4253834, 236723, AH2173830, EA2173830, PS2173830.

Description

This wiring harness assembly routes power and signals between the appliance's components to restore proper electrical connections and reliable operation. Replaces a damaged or worn harness to help resolve intermittent power, control failures, or non-responsive circuits. What it does:

• Provides the factory-configured wiring paths and connector interfaces between controls, sensors, and motors
• Restores lost or intermittent electrical connections that cause components to stop working or respond erratically
• Enables proper signal and power distribution required for normal appliance operation
• Reduces risk of shorts or open circuits caused by frayed wires or broken terminals

What's included:

• One complete wiring harness assembly as shown

Install notes:

• Disconnect power at the breaker or unplug the appliance before starting work
• Match connectors and wire colors to the original harness; secure routing to prevent pinching or chafing
• Use proper wire-management and strain relief; replace any damaged clips or fasteners
