Whirlpool W10209506 Switch Harness (Wire Harness) OEM Part

Manufacturer's Part Number: W10209506
Genuine Whirlpool part
Appliance Compatibility Tool
$32.76

Secure and trusted checkout with

Out Of Stock

Usually ships within 4 - 14 days

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10209506 replaces AP4500407, 1551621, AH2372223, EA2372223, PS2372223.

Description

This switch harness connects the appliance's control switch to the main wiring, restoring reliable switch-to-board signaling for normal operation. It replaces a damaged or worn harness to help resolve intermittent or non-responsive switch behavior. What it does:
  • Provides the factory wiring connection between the control switch and the appliance wiring harness
  • Restores proper electrical signaling when a switch fails to register or works intermittently
  • Replaces frayed, melted, or broken wires and connectors that cause control issues
  • Helps eliminate erratic or non-functioning switch behavior related to damaged wiring
What's included:
  • One switch harness as shown
Install notes:
  • Disconnect power to the appliance before inspecting or replacing the harness
  • Match connector shapes and pin counts; route harness to avoid heat or pinch points
  • Secure connectors fully until they click; do not force mismatched plugs

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Whirlpool W10209506 Switch Harness (Wire Harness) OEM Part

Part Number:
OEM13501230
Manufacturer's Part Number:
W10209506

Fits 9 models

ManufacturerModel NumberDescription
Jenn-AirJB36NXFXLW03Refrigerator
Jenn-AirJB36NXFXLW04Refrigerator
Jenn-AirJB36NXFXLW05REFRIGERATOR
MaytagJB36NXFXRW00Refrigerator
Jenn-AirJB36NXFXRW01Refrigerator
Jenn-AirJB36NXFXRW02Refrigerator
Jenn-AirJB36NXFXRW03Refrigerator
Jenn-AirJB36NXFXRW04Refrigerator
Jenn-AirJB36NXFXRW05REFRIGERATOR
