Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Washer Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number 8183254 replaces AP3966410, 1200661, AH1486345, EA1486345, PS1486345, W10168511, W10203273.
Description
This wire harness routes electrical connections between components to restore reliable power and signal flow. It replaces a damaged or frayed harness to reduce connection faults and intermittent operation. What it does:
- Reconnects control, power, or sensor circuits to restore normal appliance operation
- Replaces damaged, burned, or broken wires and terminals that cause intermittent power or failures
- Helps eliminate arcing, shorts, or loose-connection symptoms like no-start, no-heat, or control unresponsiveness
- Maintains factory wiring layout and terminal arrangement for correct component communication
What's included: One complete wire harness as shown Install notes:
- Disconnect power to the appliance before starting any work to avoid electric shock
- Match wire colors and terminal styles to the original harness; secure connections firmly
- Inspect connectors, clips, and mounting points; replace any damaged hardware
