Whirlpool W10260282 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10260282 replaces AP5607061, AH3632594, EA3632594, PS3632594.

Description

This wire harness routes power and control signals between oven components so the range's controls and heating elements receive reliable electrical connections. Replacing a damaged harness restores proper communication and power flow. What it does:

• Connects control board, sensors, switches, and heating elements for proper operation
• Carries power and control signals to enable burners, oven functions, and display responsiveness
• Commonly fails from heat, abrasion, or connector damage
• Symptoms include intermittent operation, no heat, unresponsive controls, or visible burned/melted wires

What's included: One wire harness as shown Install notes:

• Disconnect all power before starting any repair to avoid shock or injury
• Handle connectors carefully; match wire colors and connector shapes during reassembly
• Secure harness routing with existing clips and retainers to prevent heat or abrasion damage
• Test appliance functions after installation
