Whirlpool W10271989 Wire Harness (Main Control), 1 OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10271989 replaces AP4567599, 1874081, AH3407324, EA3407324, PS3407324.

Description

This wire harness routes power and signals between the appliance control and internal components, restoring reliable electrical connections for normal operation. It replaces a damaged or frayed harness to help resolve intermittent power or control issues. What it does:

• Provides the bundled wires and connector plugs that link the main control to motors, switches, sensors, and heating elements
• Restores broken or corroded connections that can cause intermittent operation or failure to start
• Helps address symptoms such as controls not responding, burners/heater not powering, or intermittent motor/pump operation
• Matches OEM connector groupings to ensure correct plug fit and routing when replacing the original harness

What's included:

• 1 wire harness as shown

Install notes:

• Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
• Compare the replacement harness to the original to ensure connector types and wire routing before installing
• Secure harness routing away from heat sources and sharp edges; use existing clips or ties
• If you see burnt connectors or melted insulation, inspect surrounding components for underlying faults before restoring power
