Whirlpool W10434804 Wire Harness (Electrical), 1 Pack OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10434804 replaces AP5589889, AH3507972, EA3507972, PS3507972.

Description

This wire harness routes power and signals between the appliance control and components to restore reliable electrical connections. Replacing a damaged harness helps stop intermittent operation and loss of power to affected parts. What it does:

• Connects control board, switches and motors so circuits can communicate and receive power
• Replaces frayed, burned or broken wiring that causes intermittent operation
• Restores circuit continuity when connectors are corroded or loose
• Prevents shorts and electrical faults from damaged insulation or broken leads

What's included: One complete wire harness assembly Install notes:

• Disconnect power before starting and verify the appliance is de-energized
• Take photos of the original routing and connector positions to aid reassembly
• Route and secure the harness away from moving parts and heat sources; ensure connectors are fully seated
• If you see melted connectors or other damage to nearby components,
