Whirlpool W10508659 Wire Harness (Main Wiring Assembly), 1 Harness OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10508659 replaces AP5670966.

Description

This wire harness is the factory-style wiring assembly that connects the appliance's electrical components, restoring reliable electrical routing and control. It replaces damaged or frayed wiring to help return normal operation. What it does:

• Routes power and signals between controls, switches, motors and sensors.
• Replaces broken, burned, or frayed wires that can cause loss of function.
• Helps stop intermittent power, no-start conditions, and control communication issues.
• Prevents arcing or shorting from damaged insulation when installed correctly.

What's included:

• One complete wire harness assembly.

Install notes:

• Turn off and disconnect power before servicing; confirm with a meter.
• Match connector shapes and pin counts to the existing harness during replacement.
• Secure harness away from heat, moving parts, and sharp edges; use existing clips.
