Best Seller
Manufacturer Part

Whirlpool W10530091 Wire Harness (Main Control Connector) OEM Part

Manufacturer's Part Number: W10530091
Genuine Whirlpool part
Appliance Compatibility Tool
$18.83

Secure and trusted checkout with

Out Of Stock

Usually ships within 4 - 14 days

Call us 1-877-477-7278
Need Help? Chat with a Pro

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10530091 replaces AP5803317.

Description

This wire harness connects the appliance control and components, restoring reliable electrical connections so your appliance powers and controls operate correctly. It replaces a damaged or faulty harness assembly to help stop intermittent power or control issues. What it does:
  • Routes power and signal wires between the control board and components
  • Reestablishes lost or damaged connections that can cause intermittent or complete loss of function
  • Helps eliminate symptoms such as no power to controls, unresponsive buttons, or components not operating
  • Prevents shorts and arcing from frayed or exposed wires when installed correctly
What's included:
  • One wire harness assembly
Install notes:
  • Disconnect power (and water, if applicable) before starting any repair
  • Compare connectors and routing to the original harness; install in the same orientation and secure all retaining clips
  • Avoid stretching or pinching wires; ensure terminal connections are fully seated

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Whirlpool W10530091 Wire Harness (Main Control Connector) OEM Part

Part Number:
OEM17409960
Manufacturer's Part Number:
W10530091

Fits 28 models

ManufacturerModel NumberDescription
MaytagMMV4205DB0MICROWAVE
MaytagMMV4205DB1MICROWAVE
MaytagMMV4205DE0MICROWAVE
MaytagMMV4205DE1MICROWAVE
MaytagMMV4205DH0MICROWAVE
MaytagMMV4205DH1MICROWAVE
MaytagMMV4205DS0MICROWAVE
MaytagMMV4205DS1MICROWAVE
MaytagMMV4205DW0MICROWAVE
MaytagMMV4205DW1MICROWAVE
MaytagMMV5219DE0MICROWAVE
MaytagMMV5219DH0MICROWAVE
MaytagMMV5219DS0MICROWAVE
WhirlpoolWMH53520CB1MICROWAVE
WhirlpoolWMH53520CE1MICROWAVE
WhirlpoolWMH53520CH1MICROWAVE
WhirlpoolWMH53520CS1MICROWAVE
WhirlpoolWMH53520CW1MICROWAVE
MaytagYMMV4205DB0MICROWAVE
MaytagYMMV4205DE0MICROWAVE
MaytagYMMV4205DH0MICROWAVE
MaytagYMMV4205DS0MICROWAVE
MaytagYMMV4205DW0MICROWAVE
WhirlpoolYWMH53520CB0MICROWAVE
WhirlpoolYWMH53520CE0MICROWAVE
WhirlpoolYWMH53520CH0MICROWAVE
WhirlpoolYWMH53520CS0MICROWAVE
WhirlpoolYWMH53520CW0MICROWAVE
