Whirlpool W10543253 Wire Harness (Complete Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10543253 replaces AP5684943, 3021608, PS7783655, W10470760.

Description

This wire harness is the assembled wiring needed to replace a worn, damaged, or failed harness that connects appliance components and restores reliable power and signal paths. It helps return normal operation by replacing frayed or broken wires and connectors. What it does:

• Replaces the factory wiring assembly that links controls, switches, sensors and motors
• Restores electrical connections that can cause no-start, intermittent operation, or failed cycles
• Eliminates problems caused by loose, corroded, or damaged wires and terminals
• Prevents arcing or shorts from exposed or broken conductors when properly installed

What's included:

• One complete wire harness assembly as shown

Install notes:

• Always disconnect power (unplug or shut off breaker) before servicing electrical components
• Verify routing and connector orientation match the original harness before securing
• Avoid stretching or pinching wires; secure with existing clips or fasteners
• If any connector or terminal appears damaged, replace the harness rather than attempt field repairs
