Whirlpool W10603947 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10603947 replaces AP5970944.

Description

This genuine replacement wire harness routes power and control signals between appliance components, restoring reliable electrical connections and normal operation. Use it when existing wiring is damaged, frayed, or causing intermittent faults. What it does:

• Connects control board, switches, sensors, and motors so the appliance components receive power and communicate.
• Replaces damaged or worn wiring that can cause intermittent operation or component failure.
• Helps resolve symptoms like parts not powering up, inconsistent cycles, or communication-related error codes.
• Provides factory-style connectors and routing to match original electrical layout.

What's included: One replacement wire harness assembly as shown. Install notes:

• Disconnect power and, if applicable, gas supply before starting any repair.
• Compare the harness to the original to ensure connectors and routing match before installing.
• Route and secure the harness away from heat sources and moving parts; use wire ties if needed.
