Whirlpool W10634454 Wire Harness (Main Wiring Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10634454 replaces AP5954958.

Description

This wire harness routes power and control signals between a range of appliance components to restore proper electrical connections and reliable operation. It replaces a damaged or worn harness to help fix intermittent or complete loss of function. What it does:

• Connects control board, motors, switches and sensors so circuits complete and communicate
• Restores power and signal paths that cause intermittent runs, no-starts, or unresponsive controls
• Replaces frayed, burned, or broken wires and damaged connector ends
• Ensures correct routing to avoid pinched or chafed wiring that can lead to shorts

What's included: One complete wire harness as shown Install notes:

• Disconnect power (unplug or shut off breaker) before beginning any work
• Handle connectors gently; align pins before seating to avoid damage
• Route harness following OEM wire paths and secure with existing clips or ties
• Test appliance operation after installation and re-check connections for tight fit
