Whirlpool W10683007 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10683007 replaces AP5949847, W10515652.

Description

This genuine replacement wire harness routes power and signals between the appliance control and components so devices operate reliably. It restores damaged or worn wiring connections for safe, consistent performance. What it does:

• Carries power and control signals between the main control and components
• Replaces frayed, cut, or burned wiring that can cause intermittent operation
• Helps resolve symptoms like components not receiving power, intermittent cycles, or electrical faults
• Maintains correct connector routing and secure plug connections for reliable function

What's included: One wire harness. Install notes:

• Disconnect power to the appliance before starting any work.
• Note or photograph connector locations and wire routing before removal to ensure correct reinstallation.
• Handle connectors by the housings; avoid pulling on wires or bending pins.
• Secure harness with existing clips or ties and inspect surrounding insulation for heat or abrasion damage.
