Whirlpool W10694682 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10694682 replaces AP5987682.

Description

This wire harness assembly routes power and signals between appliance components to restore proper electrical connections and reliable operation. It replaces a damaged or worn harness to help eliminate intermittent power, control failures, or no-start conditions. What it does:

• Provides factory-style wiring connections between control, motor, heating element, and other components
• Restores lost or intermittent electrical continuity that can cause no-start or inconsistent operation
• Replaces frayed, burnt, or corroded wiring and terminals that create safety or performance issues
• Ensures correct wire routing and secure terminals to prevent shorts and improve reliability

What's included:

• One complete wire harness assembly with terminals and connectors as shown

Install notes:

• Disconnect all power to the appliance before starting; follow lockout/tagout for safety
• Compare the harness to the original for matching connector types and lengths before installing
• Route and secure wiring away from moving parts and heat sources; use retained clips or ties
