Whirlpool W10694686 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10694686 replaces AP5984265.

Description

This wire harness assembly routes power and signals between an appliance's control and internal components so circuits operate reliably. It replaces a damaged or worn harness to restore consistent electrical connections and safe operation. What it does:

• Connects control board to motors, switches, heaters, or sensors depending on model
• Enables proper power and signal flow for normal appliance cycles
• Commonly replaced when controls are intermittent, appliance won't start, or circuits short
• Prevents loose or frayed wires that can cause arcing or failure

What's included: One complete wire harness assembly as shown. Install notes:

• Always disconnect the appliance from power before starting work.
• Verify connector orientation and routing; match harness clips and ties to original locations.
• Inspect connectors and wiring for damage; replace if any exposed conductors or melted insulation are found.
