Whirlpool W10702047 Wire Harness (Electrical Assembly), 1 OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10702047 replaces AP5981601.

Description

This wire harness is the factory-style electrical assembly that connects multiple components so your appliance receives power and control signals reliably. Replacing a damaged harness restores proper electrical connectivity and helps prevent shorts. What it does:

• Routes and connects power and signal wires between controls, motors, switches, and sensors
• Replaces frayed, melted, or corroded wiring that can cause intermittent operation or no power
• Restores proper connections that may eliminate burning smells or visible arcing at terminals
• Ensures plug-and-play fit when the original harness is removed and the new one is installed

What's included:

• One complete wire harness assembly as pictured

Install notes:

• Disconnect all power (unplug or switch off breaker) before starting work
• Take photos or label connectors to ensure correct reassembly
• Route the harness along original clips and fasteners; avoid pinching or contact with hot surfaces
• If you see damaged connectors or melted insulation on other parts, inspect and replace those components as needed
