Whirlpool W10702049 Wire Harness (Wiring Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10702049 replaces AP5971129.

Description

This wire harness connects your appliance's control and power circuits to restore reliable electrical flow and proper component communication. Designed to replace a damaged or frayed harness to help stop intermittent power or control failures. What it does:

• Routes power and signals between the control board and components so controls and heating elements receive proper voltage
• Replaces damaged, melted, or corroded wiring that can cause intermittent operation or loss of function
• Helps resolve symptoms such as unresponsive controls, intermittent heating, or components not receiving power
• Uses the OEM connector ends and wire grouping to fit the original routing and connections

What's included: One complete wire harness assembly as shown Install notes:

• Disconnect power at the breaker before starting work to avoid shock or damage
• Verify harness routing and connector orientation match the original before final connection
• Inspect connectors and mating terminals for damage; replace any burned terminals
• Basic hand tools needed;
