Whirlpool W10716324 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10716324 replaces AP5982120.

Description

This wire harness connects the dryer's control and components to deliver power and signals, restoring reliable electrical connections. It's a direct-fit replacement when the original wiring is damaged or terminals are corroded. What it does:

• Routes and links power and control signals between the console, motor, heater, and other dryer components
• Replaces cracked, frayed, burned or loose wires and terminals that cause intermittent operation
• Resolves symptoms like no heat, no start, intermittent cycles, or components that don't respond
• Ensures proper connector fit and correct wire routing when installed as directed

What's included:

• One replacement wire harness as shown

Install notes:

• Disconnect power (unplug or turn off breaker) before beginning any repairs
• Take reference photos of wire routing and connector positions before removal to ensure correct reassembly
• Match all connector shapes and pin positions; route and secure harness away from moving or hot parts
• If you detect melted insulation or a short, inspect surrounding components and replace any damaged parts before re-energizing
