Whirlpool W10744902 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10744902 replaces AP5982241, 4282152, PS11702938.

Description

This replacement wire harness routes power and control signals between the appliance's electrical components to restore proper electrical connections and reliable operation. Use it to replace a damaged or worn wiring assembly. What it does:

• Connects control board, motors, sensors and/or switches to provide power and signal paths
• Restores lost or intermittent electrical connections caused by frayed, burnt, or broken wires
• Helps eliminate symptoms such as no-start, intermittent operation, or dead circuits to specific components
• Maintains proper routing and connector fit to prevent shorting or chafing

What's included: One wire harness as shown Install notes:

• Disconnect power (unplug or shut off breaker) before starting any repair
• Compare connectors and wire colors to the original harness to ensure correct replacement
• Route harness away from sharp edges, moving parts and high-heat areas; secure with clips or ties as originally arranged
