Best Seller
Manufacturer Part

Whirlpool W10746377 Wire Harness (Main Connector Assembly) OEM Part

Manufacturer's Part Number: W10746377
Genuine Whirlpool part
Appliance Compatibility Tool
No longer available

This part is discontinued by the manufacturer and is no longer available for purchase.

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10746377 replaces AP6237796, W10572206.

Description

This wire harness is the factory-style connector assembly that routes power and signals between the appliance control and components, restoring reliable electrical connections for normal operation. What it does
  • Re-establishes secure electrical connections between the control board and components so controls and functions respond correctly
  • Commonly used when intermittent operation, no power to components, or error codes indicate open/shorted wiring
  • Prevents arcing and poor contact caused by damaged or corroded wires and terminals
  • Restores proper signal and power paths to switches, motors, heaters or sensors when original harness is faulty
What's included One wire harness assembly Install notes
  • Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
  • Take photos or label connectors before removal to ensure correct reassembly
  • Route and secure the harness away from sharp edges and moving parts; avoid pinching or excessive bending
  • If terminals are damaged, replace the harness rather than attempting repairs to ensure safe, reliable connections

Have questions? Ask our pros!

Contact us in a way that is convenient for you

Call us 1-877-477-7278
Need Help? Chat with a Pro
Or ask a question by filling in the form

Share your thoughts with other customers

Ask a Question

Cross Reference Information

Whirlpool W10746377 Wire Harness (Main Connector Assembly) OEM Part

Part Number:
OEM18713397
Manufacturer's Part Number:
W10746377

Fits 16 models

ManufacturerModel NumberDescription
Whirlpool7MWFW72HEDW0WASHER
Whirlpool7MWFW75HEFW0WASHER
Whirlpool7MWFW75HEFW1Washer
CrosleyCFWH4084GW0Washer
MaytagMHW3000BG2WASHER
MaytagMHW3000BW2WASHER
MaytagMHW4000BW2WASHER
AmanaNFW5700BW1Washer
AmanaNFW5800DW0Washer
WhirlpoolWFW70HEBW2WASHER
WhirlpoolWFW72HEDW0LAUNDRY, RESIDENTIAL, WASHER
WhirlpoolWFW7540FW0Washer
WhirlpoolWFW7590FW0WASHER
WhirlpoolWFW75HEFW0WASHER
WhirlpoolWFW80HEBC2WASHER
WhirlpoolWFW80HEBW2WASHER
