Whirlpool W10786099 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10786099 replaces AP5988230.

Description

This wire harness connects the appliance's control and power circuits to internal components, restoring reliable electrical connections and proper function. It replaces a damaged or corroded harness to help resolve intermittent or lost power and component failures. What it does:

• Transfers power and signals between the control board and internal components (motors, valves, sensors)
• Replaces damaged, burned, or corroded wiring that can cause intermittent operation or component failure
• Commonly used to address no-power, intermittent power, or non-responsive controls tied to wiring faults
• Provides factory-fit connectors for a direct replacement when the original harness is worn or damaged

What's included:

• One wire harness as shown

Install notes:

• Disconnect power (unplug or switch off breaker) before beginning any repair
• Handle connectors gently; match each connector to its mating component and ensure full engagement
• Route and secure the harness away from moving parts and heat sources; avoid pinching or sharp edges
