Whirlpool W10797420 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10797420 replaces AP6037701.

Description

This replacement wire harness routes power and signals between oven components so controls and safety devices communicate reliably. It helps restore proper electrical connections for safe, consistent operation. What it does:

• Replaces a damaged or burned harness to restore electrical continuity to controls and sensors
• Carries power and signal lines between control board, switches, and safety devices
• Addresses symptoms like intermittent power, no response from controls, or visible wiring damage
• Helps prevent shorts or arcing caused by frayed or loose connector ends

What's included: One replacement wire harness. Install notes:

• Disconnect power before servicing to avoid shock or injury
• Inspect connectors and routing; replace if pins or insulation are damaged
• Secure harness away from heat sources and moving parts to prevent premature wear
