Whirlpool W10834331 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10834331 replaces AP6237817, W10877902.

Description

This replacement wire harness routes power and signals between a dryer's electrical components so the appliance can run safely and reliably. It replaces a damaged or worn harness to restore proper electrical connections. What it does:

• Connects control, motor, heating, and safety components through factory-style connectors
• Restores interrupted electrical paths that can cause no-start or intermittent operation
• Helps prevent loose or damaged wiring that can trigger error codes or unsafe operation
• Supports proper function of switches, thermostats, and other serviceable parts

What's included:

• One factory-style wire harness with connectors as shown

Install notes:

• Disconnect power (unplug electric or shut off breaker; turn off gas and unplug gas dryers) before servicing
• Follow the appliance's wiring diagram and route the harness to avoid heat or pinch points
• Ensure all connectors are fully seated and secured with any clips or fasteners provided
