Whirlpool W10836954 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10836954 replaces AP5988705, W10610075.

Description

This wire harness connects the appliance's control and power circuits so electrical signals and power reach motors, sensors and switches. Replacing a worn or damaged harness restores reliable electrical connections and control function. What it does

• Routes power and signal wiring between the control board and components so the appliance operates safely.
• Restores intermittent or lost power to motors, valves or lights when wiring is broken or shorted.
• Prevents shorts and arcing caused by frayed or damaged insulation.
• Helps eliminate control errors or non-responsive controls when worn harness connectors fail.

What's included

• One wire harness assembly as shown.

Install notes

• Disconnect power (unplug appliance or shut off breaker) before starting—verify power is off.
• Handle connectors by the plug housings; avoid pulling on individual wires.
• Match connectors and routing to the original harness; secure with existing clips or ties.
