Whirlpool W10850395 Wire Harness (Multi-Connector) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10850395 replaces AP5989698, 4383727, PS11731146, W10514907, W10566904, W10641985.

Description

This wire harness routes power and signals between controls and components, restoring reliable electrical connections. It replaces a damaged or worn harness to help eliminate intermittent operation and restore proper appliance function. What it does:

• Connects control board, switches, and components for power and signal transmission
• Replaces frayed, melted, or broken wiring that can cause intermittent or no operation
• Helps resolve symptoms like control failures, non-starting cycles, or components not responding
• Provides factory-style connectors and color-coded leads for correct hookups

What's included: One replacement wire harness as shown Install notes:

• Disconnect power (unplug or shut off breaker) before starting any work
• Label or photograph original connector locations to ensure correct reassembly
• Route harness away from heat sources and sharp edges; secure with existing clips or fasteners
• Test appliance operation after installation; inspect for loose connections or damaged insulation
