Whirlpool W10877735 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10877735 replaces AP6039012.

Description

This wire harness connects electrical components to restore reliable power and signal routing in the appliance. Replaces a damaged or burned harness to help eliminate intermittent operation, no-power issues, or shorts. What it does:

• Provides the main wiring connections between controls, motors, heaters, and sensors
• Restores continuity when frayed, pinched, or melted wiring causes failures
• Helps stop intermittent power, non-starts, or components that lose function
• Matches OEM routing and connector types for a correct fit and electrical interface

What's included: One complete wire harness as shown Install notes:

• Disconnect power before servicing to avoid shock or injury
• Handle connectors gently and ensure secure, full seating of each plug
• Secure wire routing with existing clips/retainers to prevent chafing
• If damaged connectors or terminals are present, replace the entire harness rather than splicing
