Whirlpool W10877738 Wire Harness (Control / Power) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10877738 replaces AP6039013.

Description

This wire harness routes power and control signals between the appliance's control board and internal components, restoring reliable electrical connections for responsive operation and proper control function. What it does:

• Transfers power and low-voltage signals between the control board and motors, sensors, valves, lights, or switches
• Replaces damaged or corroded wiring that can cause intermittent or no power to components
• Commonly used when controls, lights, or certain functions stop responding or behave erratically
• Helps prevent shorts and poor connections from causing faults or error codes

What's included:

• One replacement wire harness

Install notes:

• Disconnect power at the breaker or unplug the appliance before starting
• Document wire locations or take photos before disconnecting to ensure correct reconnection
• Route harness to avoid pinching, sharp edges, or heat sources; secure with existing clips or ties
• If exposed wires or connector damage is found at both ends, inspect mating components for damage before powering up
