Whirlpool W10889944 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10889944 replaces AP6284962.

Description

This wire harness routes power and control signals between the appliance control and internal components to restore reliable electrical connections and proper operation. Designed as a direct-replacement harness for the original wiring assembly. What it does:

• Carries power and signal connections between the control board and components (motors, valves, heaters, lights).
• Replaces damaged or frayed wiring that can cause intermittent or no power to components.
• Helps resolve symptoms like unresponsive controls, components that won't run, or intermittent operation.
• Maintains correct connector fit and wire routing to prevent shorts or pinched conductors.

What's included: One wire harness (single assembly as pictured). Install notes:

• Always unplug the appliance or shut off power at the breaker before starting work.
• Handle connectors by the housing; avoid pulling on wires and protect against pinching.
• Confirm connector orientation and full seating during reassembly; follow routing clips and harness clips.
