Whirlpool W10913117 Wire Harness (Wiring Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10913117 replaces AP6339352, 4841821, PS12577932.

Description

This wire harness connects multiple electrical components so your appliance gets reliable power and signal routing. Replacing a damaged harness restores proper electrical connections and can stop intermittent operation or complete failures. What it does:

• Routes power and control signals between the appliance control and components
• Restores missing or intermittent electrical connections that cause faults or loss of function
• Prevents shorts from damaged or frayed wiring when replaced
• Matches OEM connector locations and lengths for a direct fit

What's included:

• One complete wire harness assembly as shown

Install notes:

• Unplug the appliance or disconnect power at the breaker before starting
• Take photos of existing routing and connector positions to ensure correct reassembly
• Disconnect and reconnect connectors carefully; avoid pulling on wires
• Route harness away from sharp edges, moving parts, and high-heat areas; secure with original clips or ties
