Whirlpool W11029433 Wire Harness (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11029433 replaces AP6039078, W10404016, WPW10404016, 4461617, PS11773058.

Description

This main control wire harness routes power and signals between the appliance control board and key components, restoring reliable electrical connections for proper operation. Ideal when controls or components lose power or communication. What it does:

• Transfers power and control signals between the control board and motors, switches, sensors, or heating elements
• Replaces damaged, frayed, or corroded wiring that can cause intermittent or complete failure of functions
• Helps resolve symptoms like unresponsive controls, components not powering on, or intermittent operation
• Maintains correct connector fit and wire routing to prevent shorting or signal loss

What's included:

• One wire harness as shown

Install notes:

• Disconnect power (unplug or shut off breaker) before starting any repairs
• Compare connectors and wire colors to the old harness to confirm correct fit before installation
• Route harness along the original path and secure with existing clips or fasteners to avoid contact with moving or hot parts
