Whirlpool W11043536 Wire Harness (Control Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11043536 replaces AP6041971.

Description

This genuine wire harness routes power and signals between the appliance control and internal components so controls, lights and motors can operate correctly. It restores reliable electrical connections for affected circuits. What it does

• Carries power and control signals between the control board and parts like switches, lights and motors
• Replaces broken, burnt or frayed wiring that can cause intermittent operation or total failure
• Restores loss of function where controls, displays or components do not respond
• Prevents shorting from exposed conductors when insulation is damaged

What's included

• One wire harness assembly as shown

Install notes

• Disconnect all power before starting; verify no voltage at the appliance
• Inspect connector orientation and match keyed plugs to the mating sockets before seating
• Route harness along original wire channels and secure with clips to avoid pinch points or heat sources
