Whirlpool W11100762 Wire Harness (Control/Connection Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11100762 replaces AP6285695, 4842413, PS12347078.

Description

This wire harness routes electrical signals between the appliance control and key components so the unit can operate reliably. It replaces a damaged or worn harness to restore consistent power and signal connections. What it does

• Carries power and control signals between the control board and components
• Restores intermittent or no-operation symptoms caused by broken, frayed, or burned wires
• Helps stop sparking, shorting, or burning-odor issues when caused by a faulty harness
• Supports safe, stable operation when connectors or insulation are compromised

What's included

• One replacement wire harness as pictured

Install notes

• Disconnect power before servicing
• Inspect mating connectors and routing; replace or secure as needed to avoid pinching or heat exposure
• Use correct connector orientation and secure all fasteners; test operation after installation
• Do not attempt repairs with the appliance energized
