Whirlpool W11134593 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11134593 replaces AP6832381, W10251762, W10083480, W10233349.

Description

This wire harness routes electrical power and signals between components to restore reliable operation. It replaces a damaged or worn harness to help stop intermittent power, control issues, or components that won't activate. What it does:

• Connects power and control circuits between the control board and major components
• Restores proper electrical continuity when original wiring is frayed, burned, or broken
• Helps resolve intermittent operation, no-power conditions, or unresponsive controls caused by damaged wiring
• Maintains factory routing and connector fit for correct function and safety

What's included:

• One complete wire harness as shown

Install notes:

• Disconnect all power before starting work to avoid shock or damage
• Verify connectors are fully seated and routed per original path; replace any damaged clips or retainers
• Inspect mating connectors and terminals for corrosion or heat damage; repair both sides if needed
