Whirlpool W11190476 Wire Harness (Electrical Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11190476 replaces AP6339405, W10257163, 4844057, 74011015, PS12578211.

Description

This wire harness routes power and control signals between appliance components, restoring electrical connections for proper operation. It replaces a damaged or worn harness to help resolve intermittent power, control failures, or component non-responsiveness. What it does:

• Provides the factory wiring paths for power and signal distribution between control and components
• Restores lost or intermittent electrical connections caused by frayed, burned, or broken wires
• Helps stop symptoms such as no power to a module, controls not responding, or certain functions failing
• Matches OEM connector groups and wire lengths for a direct replacement

What's included:

• One wire harness assembly

Install notes:

• Replace only with the exact OEM harness; disconnect power before beginning work
• Take photos or label connections before removal to ensure correct reassembly
• Secure harness away from heat sources, sharp edges, and moving parts to prevent future damage
