Whirlpool W11198271 Wire Harness (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11198271 replaces AP6981270.

Description

This wire harness connects key electrical components to deliver power and signals, restoring reliable operation of the appliance. It replaces a damaged or frayed harness to stop shorts, intermittent power, or control failures. What it does:

• Routes power and control signals between modules, motors, switches, and sensors
• Replaces cracked, burnt, or corroded wiring that can cause intermittent operation
• Helps stop arcing, blown fuses, or tripped breakers caused by damaged leads
• Restores proper connections when loose or broken terminals cause errors or non-functioning components

What's included:

• One complete wire harness assembly as shown

Install notes:

• Disconnect power (unplug or turn off breaker) before inspecting or replacing the harness
• Note or label wire locations and connector orientation before removal for accurate reassembly
• Secure harness away from heat, moving parts, and sharp edges to prevent wear
• If terminals are damaged, replace the entire harness—do not splice in temporary fixes
