Whirlpool W11200304 Wire Harness (Complete) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11200304 replaces AP6976372.

Description

This wire harness routes power and signals between your appliance's controls and components to restore reliable electrical connections and function. Replaces a damaged or worn harness to help eliminate intermittent operation and loss of power. What it does:

• Provides factory-style wiring to deliver power and control signals to motors, switches, valves and sensors
• Restores connections when frayed, burnt or broken wires cause intermittent operation or components that won't run
• Helps address symptoms such as no power to a circuit, unresponsive controls, or error codes tied to open or shorted circuits
• Matches OEM connector types and lengths for a direct-fit replacement when the original harness is damaged

What's included:

• One complete wire harness assembly

Install notes:

• Disconnect power to the appliance before starting any repair to avoid shock or injury
• Compare the new harness to the old one to confirm connector locations and routing before disconnecting anything
• Route and secure the harness away from heat sources and moving parts; use existing clips or ties where applicable
