Whirlpool W11226234 Wire Harness (Wiring Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11226234 replaces AP6832424, PS12704184, W10330661, W10738951.

Description

This wire harness is the replacement wiring assembly that connects electrical components so your appliance can receive power and control signals. Replacing a faulty harness restores reliable electrical connections and helps components operate correctly. What it does:

• Routes power and signal connections between internal components for proper operation
• Replaces damaged or burnt wiring that can cause intermittent power or function failures
• Helps stop issues like lights out, controls unresponsive, or components not powering on when caused by broken wiring
• Maintains secure, insulated connections to prevent shorts or arcing when installed correctly

What's included:

• One replacement wire harness assembly

Install notes:

• Disconnect power to the appliance before beginning any repair to avoid shock or injury
• Handle connectors carefully and match connector shapes and pin counts; do not force connections
• Route the harness following original clips and channels to avoid heat or friction damage
