Whirlpool W11234406 Wire Harness (Complete Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Refrigerator Wire, Harness, Power Cord.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11234406 replaces AP6331312, W10129821, 2187826, 2206504, 2310114, 2310240, 4845191, PS12349751.

Description

Replacement wire harness that restores electrical connections between the appliance control, power and components for reliable operation and correct signaling. Use this complete wiring assembly when damaged wires or connectors cause power or control issues. What it does:

• Routes power and signal conductors between the control board, switches, motors and sensors.
• Replaces damaged, frayed or melted wiring and broken connectors that can cause intermittent operation, no-start or control failures.
• Restores factory-style plug connections and routing to help prevent miswiring and shorts.
• Matches the original connector shapes and wire colors for straightforward replacement.

What's included: One complete wire harness. Install notes:

• Disconnect power (unplug or shut off breaker) before servicing to avoid shock or injury.
• Remove and replace the harness by disconnecting connectors at the control and components; handle connectors by the plastic bodies, not the wires.
• Route the harness along the original path and secure with existing clips or fasteners to prevent rubbing or heat exposure.
