Whirlpool W11245661 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11245661 replaces AP7192566.

Description

This wire harness is the electrical assembly that connects controls and components so your appliance can receive power and signals. Replacing a damaged harness restores reliable electrical connections and helps appliances operate safely. What it does:

• Carries power and control signals between the control board and components
• Can cause no-start, intermittent power, or unresponsive controls when damaged
• Restores proper component communication when cracked wires or corroded terminals are replaced
• Prevents shorting and electrical faults when routed and secured correctly

What's included: One wire harness assembly Install notes:

• Disconnect power (unplug or switch off breaker) before starting any repair
• Inspect connectors and routing; replace if terminals are corroded or insulation is damaged
• Avoid pinching or stretching wires; secure harness with original clips and ties
