Whirlpool W11249915 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11249915 replaces AP7192582.

Description

This wire harness assembly restores factory wiring connections so controls and components receive power and signals reliably. It replaces a damaged or worn harness to help stop intermittent operation and restore normal electrical function. What it does:

• Routes and connects power and signal wires between components and the main control
• Replaces frayed, burned, or broken wiring that can cause intermittent power or component failures
• Helps resolve symptoms like controls not responding, lights or displays failing, or appliances not starting
• Maintains factory connector fit and wiring layout to ensure proper component communication

What's included: One wire harness assembly Install notes:

• Disconnect power before beginning any repair to avoid shock or injury
• Compare the replacement harness to the original for connector type and routing before installing
• Route wires along factory paths and secure with clips or ties; avoid sharp edges and heat sources
