Whirlpool W11256629 Wire Harness (Electrical Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11256629 replaces AP7192591.

Description

This wire harness routes electrical power and signals between appliance components to restore reliable connections and normal operation. It replaces a damaged or worn harness to help resolve intermittent power or control issues. What it does

• Provides organized wiring to connect controls, switches, sensors, and motors
• Restores interrupted power paths that can cause components to stop working
• Helps eliminate intermittent operation, blown fuses, or non-responsive controls due to damaged wiring
• Reduces risk of shorting from frayed or exposed conductors when properly installed

What's included One wire harness assembly as pictured Install notes

• Disconnect power at the breaker or unplug the appliance before starting
• Match connector shapes and colors; do not force connectors—ensure full seating
• Route and secure the harness along original clips and channels to avoid heat or moving-part contact
• If corrosion, burned connectors, or control damage are present, inspect related components and replace as needed
