Whirlpool W11315693 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11315693 replaces AP6872060, W10847170.

Description

This wire harness routes electrical connections to the appliance's control and components, restoring reliable power flow and signal paths for proper operation. Use it to replace a damaged or worn harness causing intermittent or failed electrical connections. What it does:

• Reconnects power and control signals between the main control and components
• Replaces frayed, burnt, or broken wiring that can cause intermittent operation
• Restores operation when lights, motors or controls lose power or respond inconsistently
• Helps eliminate arcing or exposed wires that create safety hazards

What's included: One wire harness as shown Install notes:

• Disconnect power to the appliance before starting any repair
• Handle connectors and wires gently; match connector shapes and routing during installation
• Secure routing away from heat sources and moving parts to prevent wear
