Whirlpool W11319486 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11319486 replaces AP7192600.

Description

This wire harness assembly routes power and signals between the appliance control and its components, restoring reliable electrical connections for normal operation. What it does

• Connects the control board to motors, switches, sensors and other electrical components.
• Replaces damaged, broken or corroded wiring that can cause intermittent or no power to circuits.
• Helps resolve symptoms such as no-start, unresponsive controls, intermittent function or failure of specific features.
• Prevents poor connections that can cause arcing, overheating or error codes when functioning properly.

What's included One wire harness assembly as shown. Install notes

• Disconnect power at the breaker or unplug the appliance before starting any work.
• Compare connectors and routing to the original harness; install in the same path and secure all clips.
• Handle connectors gently and ensure full engagement; do not force mismatched plugs.
