Whirlpool W11319489 Wire Harness (Main Connector Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11319489 replaces AP7192601.

Description

This wire harness routes electrical power and signals between the appliance's control and its components to restore reliable operation. Replaces a damaged or worn harness to stop intermittent faults and loss of function. What it does

• Delivers power and control signals to motors, switches, and sensors.
• Replaces frayed, melted, or broken wiring that can cause intermittent operation.
• Helps resolve symptoms like no power to components, controls not responding, or sporadic cycles.
• Restores secure connector fit where loose terminals cause connection issues.

What's included One replacement wire harness as shown. Install notes

• Disconnect all power (unplug or shut off breaker) before beginning work.
• Compare connectors and wire colors to the original harness to match before installing.
• Route wires away from moving parts and heat sources; secure with existing clips or ties.
