Whirlpool W11328034 Wire Harness (Main Wiring Harness) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11328034 replaces AP6888203.

Description

This wire harness routes electrical power and signals between the appliance control and components to restore reliable operation. Replaces a damaged or burnt harness to stop intermittent faults and restore proper circuit connections. What it does:

• Carries power and control signals between the main control, switches, sensors and motors
• Commonly used to fix intermittent operation, no-response controls, or component power loss
• Replaces damaged, frayed or heat-damaged wiring that can cause shorts or open circuits
• Ensures correct connector fit and pin alignment for reliable component operation

What's included: One wire harness. Install notes:

• Disconnect power (unplug or shut off breaker) before starting any repair
• Inspect connectors and pins for damage; replace if terminals are corroded or bent
• Route harness to match original path and secure clips/fasteners to prevent chafing
