Whirlpool W11342420 Wire Harness (Main Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11342420 replaces AP7192605.

Description

This wire harness is a factory-style main wiring assembly that delivers power and control signals between the appliance control and internal components, restoring proper electrical connections for reliable operation. What it does

• Carries power and control signals between the control board and motors, valves, heaters, sensors, or switches.
• Replaces damaged or frayed wiring that can cause intermittent operation or loss of function.
• Restores proper connector fit and routing to prevent shorts or connector overheating.
• Helps address symptoms like non-starting cycles, unresponsive controls, or components that do not run.

What's included One wire harness assembly as shown. Install notes

• Disconnect all power (unplug or shut off breaker) before starting any repair.
• Note or photograph the original routing and connector positions to ensure correct reinstallation.
• Disconnect and reconnect all connectors fully; avoid pulling on wires—use connector bodies.
• Inspect mating connectors and mounting points for damage before powering the appliance; test operation after reassembly.
