Whirlpool W11421923 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11421923 replaces AP7208220.

Description

This wire harness assembly connects the appliance's control and electrical components for reliable signal and power transmission. Replacing a damaged harness restores proper electrical connections and helps recover normal function. What it does:

• Routes power and signal between the control board and components (motors, sensors, valves).
• Replaces frayed, burnt, or broken wiring that can cause intermittent operation or component failure.
• Restores proper connector seating to eliminate loose-connection symptoms like no-start or erratic cycles.
• Prevents shorting and electrical faults when original wiring is damaged.

What's included: One assembled wire harness as shown. Install notes:

• Disconnect power to the appliance before beginning any repair.
• Handle connectors carefully; match connector shapes and pin locations before seating.
• Route harness following existing clips and channels; avoid sharp edges and heat sources.
