Whirlpool W11425741 Wire Harness (Electrical) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11425741 replaces AP7194639.

Description

This wire harness is the factory-style electrical connector assembly that routes power and control signals between components. Replacing a damaged harness restores secure connections and helps appliances regain reliable operation. What it does:

• Carries power and control signals between the control board and other components
• Restores lost or intermittent electrical connections that can cause failures
• Commonly used when the appliance has no power to certain circuits, intermittent operation, or component(s) not responding
• Prevents arcing and poor connections when installed correctly

What's included: One wire harness Install notes:

• Disconnect power (unplug or shut off breaker) before starting any work
• Note or photograph connector locations and routing before removal to ensure correct reinstallation
• Replace with this exact harness—do not splice or modify wires
• After installation, restore power and test the appliance through a full cycle to ensure proper operation
