Whirlpool W11455661 Wire Harness (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11455661 replaces AP7192633.

Description

This wire harness routes electrical connections between the appliance's control and key components, restoring proper signal and power flow so controls and components operate reliably. What it does:

• Connects control board to motors, switches, valves, and sensors for coordinated operation
• Restores power/signal paths when a damaged or broken harness causes intermittent or lost function
• Can resolve symptoms like unresponsive controls, components that won't run, or intermittent operation caused by frayed wires or loose connectors
• Provides factory-style replacement wiring and factory-style connector terminations for correct fit

What's included: One wire harness assembly as shown. Install notes:

• Disconnect power to the appliance before beginning any repair to avoid shock or injury
• Note connector locations and wire routing before removal; replace wires following the same path and secure with original clips
• Make all connections fully seated; damaged connectors or pins should be replaced rather than forced
