Whirlpool W11459154 Wire Harness (Assembly) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11459154 replaces AP7034285.

Description

This wire harness is the factory-style electrical assembly that restores reliable power and signal connections between components. It replaces a damaged or worn harness to help return the appliance to proper operation. What it does

• Carries power and control signals between components so controls, motors and sensors can operate
• Replaces frayed, burnt, or broken wiring that causes intermittent operation or component failures
• Helps stop shorts and open circuits that can prevent functions from working
• Matches OEM connector end-types to maintain original fit and routing

What's included One complete wire harness assembly as shown. Install notes

• Disconnect power (unplug or shut off breaker) before inspecting or replacing the harness
• Note connector positions and routing, or take photos, to ensure correct reinstallation
• Connectors should fully seat and locking tabs should engage; replace harness if connectors or terminals are damaged
